Extractor Resampler and Masking
This service aims at extracting the Deciduous Vegetation Layer from multiclass land cover map at 30 meters, resampling it at 2 meters and masking all the pixels, of the 2 meters stack, not overlaid by the deciduous vegetation layer.
It represents the Step 8 of the Ailanthus Workflow within the Internal Joint Initiative.
Default
- Date ( Creation)
- 2019-07-04
- Date ( Publication)
- 2021-04-02
- Status
- Under development / Pre operational
- Keywords
-
habitat mapping
- Keywords
-
data management
- Keywords
-
Overlay
- Keywords
-
masking
- Keywords
-
resampler
- Keywords
-
deciduous vegetation layer
- Keywords
-
Ailanthus
- Keywords
-
IJI
- Keywords
-
data processing
- Access constraints
- License
- Use limitation
-
The final license will be available soon
- Operation name
-
LC_map_numeric_multiclass_30m.tiff
- Description
-
It represents the output multi-class land cover map obtained from the SVM classifier at 30 meters spatial resolution. It is a multi-class map with a numeric code associated to each different class. File format: raster geotiff.
- Function
-
Input file
- Operation name
-
FAO-numeric_multiclass.txt
- Description
-
Look-up table to identify the correspondence between numeric and FAO-LCCS codes. File format: text file.
- Function
-
Input file
- Operation name
-
Stack_2dates_WV2_2m.tiff
- Description
-
It is a multi-layer file containing the two multi-season images each one with its 8 bands. File format: raster geotiff.
- Function
-
Input file
- Operation name
-
Stack_2dates_WV2_2m_masked.tiff
- Description
-
It is a multi-layer file containing the two multi-season images each one with its 8 bands in which those pixels not classified as deciduous vegetation from first stage land cover mapping are masked. File format: raster geotiff.
- Function
-
Output file
- Topic Category
- Land cover
- Service Category
-
data processing
- Service Language
- eng
- Service TRL
- TRL 7 – System prototype demonstration in operational environment
